Monoblock capsuling and labelling machine mod. D-2000

Automatic distributor for distributing and sealing tin, aluminum, complex, and PVC capsules. Made of stainless steel and complete with a rolling or thermal head, it has a solid and compact structural design. Ready for including in a bottling line, and complete with a long-lasting magazine and cap/cork checking device, it is fitted for use with a specific type of capsule and cylindrical bottle. Designed to be highly user-friendly, it is easy to install and complete with safety shields.

Working direction from left to right
Maximum output: 2500 bottles per hour with the thermal head
Maximum output: 1000 bottles per hour with the rolling head
MADE by OMB ITALIA Srl
Monobloc mod. D-2000 2T

With a dual-head handling system
Complete with two thermal heads or two rolling heads
Maximum output: 2000 bottles per hour with the thermal head
Maximum output: 1000 bottles per hour with the rolling head

Monobloc mod. D-2000 mech with needles

Horizontal version, with a double magazine
Device for mechanically separating the capsules
Maximum output: 3000 bottles per hour with the thermal head
Maximum output: 1000 bottles per hour with the rolling head

Monobloc mod. D-2000 champagne

Device for sealing large capsules
Head handling unit for large capsules +2 capper bells for sealing capsules complete with photocell for centering wording on the large capsule in relation to alignment lines
Device equipped for a specific type of large capsule and bottle.
Maximum output: 1000 bottles per hour
